Punch Geometry Overview

Before checking the tang, it is helpful to understand the overall dimensions that affect your bend. As shown in the diagram:

• H (Height): The overall height of the tool from the tip to the top of the tang.
• α (Alpha): The included angle of the punch tip.
• R (Radius): The specific radius of the punch tip.

By providing these measurements along with your tang style, our team can ensure a perfect match for your fabrication needs.
